HN 3DOF Motion Kit V2

Big Piston. Tanky Build. Same Legendary Motion.
The HN 3DOF Motion Kit V2 is the next-generation motion system for serious sim racers and flight simmers. Built tougher, designed smarter, and engineered for industrial-grade performance — this is motion, evolved.

V2 introduces a larger round actuator design, 2505 TBI ball-bearing lead screws, and a more robust mechanical structure — delivering the same immersive motion with a bold, upgraded form.

What’s New in V2

Round Actuator Design – thicker profile for a rugged, pro-grade aesthetic
2505 Ball-Bearing Lead Screws – premium TBI components for smoother, long-life operation
Redesigned Mechanics – internal reinforcements for greater rigidity and improved durability
Same Push & Pull Design – trusted motion style with cleaner housing and stronger build

Hands-On Assembly – Build It. Understand It. Master It.

The HN 3DOF Motion Kit V2 ships in a partially assembled state, giving users the opportunity to:

✅ Learn the system inside and out
✅ Wire and configure their setup for maximum compatibility
✅ Tailor layout and placement to perfectly fit their cockpit

No soldering required – just real-world connection to the gear that moves you.

V1 vs. V2 Comparison

Feature	V1 (Legacy)	V2 (New)
Actuator Style	Square tube	Round tube
Leadscrew	1610 TBI Ball-Bearing Screw	2505 TBI Ball-Bearing Screw
Motion Speed	Up to 500mm/s	Up to 250mm/s (torque-tuned)
Travel Distance	150mm	150mm
Motion Design	Push & Pull	Push & Pull
Max Load Capacity	300kg	350kg
Controller Options	Thanos4U / ThanosAMC	Thanos4U / ThanosAMC

Key Features

Industrial-Grade Actuators with NSK bearings and 2505 TBI ball-bearing screws
Powerful, Silent Servo Motors
200kg Push Force per Actuator with 150mm travel
Rugged & Quiet Design – engineered for high-end sim environments
Supports up to 350kg Total Load (including cockpit + driver)
Fully Compatible with Thanos Motion Controllers – 4-axis or 7-axis setups

Software Compatibility

Works seamlessly with:

SimHub Motion
SimRacingStudio (SRS)
(Software licenses sold separately)

What’s in the box:

4 x Actuator
4 x Servo Motor and driver
4 x DB25 Cable
USB Cable
PDU Power Board
Controller of your choice
4U Cabinet
Bolts & Nuts

Disclaimer:

The HN 3DOF Motion Kit must be used in a safe and controlled environment, free from obstructions, and with appropriate safety precautions in place.
Customers use this product at their own risk. Improper installation, configuration, or use can result in damage to equipment or personal injury.
The system includes moving mechanical parts that can pose a risk of injury if not handled properly. Keep hands, fingers, and objects away from actuators and other moving components during operation.
The maximum safe weight rating for the system is 350kg (including the user and cockpit setup). Exceeding this limit may lead to mechanical failure or safety hazards.
This product is intended for simulation purposes only. The manufacturer is not responsible for damage or injury resulting from misuse, modification, or failure to follow instructions.
